DALI-2 CS THP-AQ
Art. Nr.: 86457786-AQ-__

Product link: https://www.lunatone.com/en/product/dali-2-cs-thp-aq/
Datasheet: https://www.lunatone.com/wp-content/uploads/2024/06/86457786-DALI2_CS-THP-AQ_EN_D0129.pdf

for installation in luminaires
with Application Controller (Instance mode can be activated)
sensor for motion, light, temperature, relative humidity, air pressure & air qualityCompact sensor module with motion detection (PIR) and light intensity measurement for DALI and DALI-2 systems. The module can either be used to directly control the DALI system (application controller) or simply to gather measurements for a building management system (instance mode).
The DALI-2 CS can be configured with the DALI Cockpit Software to send various DALI commands upon motion detection (on/off, max, min, scene, …) to either the entire DALI system, groups, or individual addresses.
The module contains a light sensor and can automatically adjust room lighting (constant light control). 4 operating modes are supported: motion triggered constant light control; motion triggered lighting; constant light control; light control via threshold switches.
Additionally independent threshold switches can be configured for the sensor values: temperature, humidity, air pressure and air quality.
In addition, alternative behaviour and parameters can be set, for example to change between different destination addresses or light values.
Multiple sensors within one group will synchronise automatically.
The device is powered directly by the DALI bus. The measured values can be read out via the DALI line.

DALI-2 CS THP-AQ LE is suitable for installation in luminaires.
The housing colour is black or traffic white RAL 9016 (-W16).
Factory setting: motion detection and 10min hold time before the off command.

DALI-2 CS THP-AQ
Art. Nr.: 86457786-AQ-LE-__

Product link: https://www.lunatone.com/en/product/dali-2-cs-thp-aq-le/
Datasheet: https://www.lunatone.com/wp-content/uploads/2024/06/86457786-DALI2_CS-THP-AQ_EN_D0129.pdf

DALI-2 RM16 I HS
Art. Nr.: 86456203-I-HS

DALI-2 RM16 IS HS
Art. Nr.: 86456203-IS-HS

Product link: https://www.lunatone.com/en/product/dali-2-rm16-i-hs-is-hs/
Datasheet: https://www.lunatone.com/wp-content/uploads/2024/06/86456944_86456203_DALI-2_RM8_RM16_RM25_EN_D0130.pdf

control unit with 4 LEDs to indicate selected groups or scenes

DALI-2 Touchpanel
Art. Nr.: 24035290

Product link: https://www.lunatone.com/en/product/dali-2-touchpanel-04/
Datasheet: https://www.lunatone.com/wp-content/uploads/2024/04/24035290_DALI-2_Touchpanel04_EN_D0128.pdf

Application example:

DALI-2 PS12 100mA serves as power supply for the DALI bus system. Adhering to standard voltage and current limitations, alongside precise timing, it ensures dependable bus communication. With the guaranteed output current of 100mA a small DALI line can be supplied with up to 50 standard DALI devices. The supply voltage ranges from 9V DC to 16V DC. DALI-2 PS12 100mA is suitable for flush-mounted installation boxes or for integration into protection class II devices.

DALI-2 PS12 100mA
Art. Nr.: 24033444-12VDO

Product link: https://www.lunatone.com/en/product/dali-2-ps12-100ma/
Datasheet: https://www.lunatone.com/wp-content/uploads/2024/04/24033444-12VDO_DALI-2_PS12_100mA_EN_D0127.pdf

Want to know more about DALI?
Courses 2024 – Lunatone controller applications

Content:

• Lunatone product portfolio
• DALI basics
• Concept Lunatone Controls / Examples
• DALI Cockpit Software Tool
• Hands on Training 1: Applications Broadcast
• Hands on Training 2: Applications Addressed
• Error diagnosis and tests

Date and Location:
Lunatone headquarters in 1210 Vienna, Austria
Course dates can be found below
For courses in German language see German website.

Requirements & Costs:
For registration, please send an e-mail including your complete address and desired date to: jelinek@lunatone.at
The number of participants is min. 5 and max. 12 people. The order of registration follows the date of receipt. Registrations are binding.

Euro 490,- (excluding VAT)
included is 1 piece of DALI USB 30mA worth Euro 275,92.
Please bring a laptop with installed DALI Cockpit software.

Lunatone Cloud Service

Product link: https://www.lunatone.com/en/product/lunatone-cloud-service/
Datasheet: https://www.lunatone.com/wp-content/uploads/2024/02/DALI-2_IoT_Cloud_Support_EN_M0027.pdf

DALI-2 4Ch PD
Art. Nr.: 86451975-HS

Product link: https://www.lunatone.com/en/product/dali-2-4ch-pd/
Datasheet: https://www.lunatone.com/wp-content/uploads/2024/01/86451975_DALI-2_4Ch_PD_EN_D0126.pdf

DALI-2 4Ch E-RM
Art. Nr.: 86450563-HS

Product link: https://www.lunatone.com/en/product/dali-2-4ch-e-rm/
Datasheet: https://www.lunatone.com/wp-content/uploads/2024/01/86450563_DALI-2_4Ch_E-RM_EN_D0125.pdf

Lunatone offers DALI products for almost all applications. With this online catalog we would like to assist you with finding the right products.

2 new lenses for DALI-2 CS combi sensor:

Long distance lens
for high bay applications, 10x30m at installation hight of 15m
Article number addition: -30
Lens type -30 has an ultra wide and long distance detection type and is suitable for application in high bay aisles. The maximum mounting height is about 15m. For this installation height of 15m it gains a field of view of approx. 30m x 12m, with 188 detection zones which minimize blind spots.

Corridor lens
wide angle for corridors
Article number addition: -C
Lens type -C is a “hammerhead lens” with a detection range of up to 5m and an asymmetrical alignment. The horizontal detection angle is up to 150°, while the vertical is asymmetrical (+ 10 °, -25 °). The lens is particularly recommended for wall mounting e.g. in corridors.

the lenses are suitable for:

DALI-2 CS
website: https://www.lunatone.com/en/product/dali-2-cs/
datasheet: https://www.lunatone.com/wp-content/uploads/2021/07/86458670_DALI2_CS_EN_D0097.pdf

DALI-2 CS Integration
website: https://www.lunatone.com/en/product/dali-2-cs-integration/
datasheet: https://www.lunatone.com/wp-content/uploads/2021/07/86458670-INT_86457786-INT_DALI2_CS-Integration_EN_D0098.pdf

DALI-2 RTC+ Timer
Art. Nr.: 86457142

Product link: https://www.lunatone.com/en/product/dali-2-rtc-plus-timer/
Datasheet: https://www.lunatone.com/wp-content/uploads/2023/10/86457142_DALI-2_RTC_Timer_EN_D0122.pdf

3Watt DALI LED driver with an input voltage of 220-240V AC. Devices with different output voltage ranges / output currents are available: 350mA, 500mA and 700mA.

The device is controlled via one DALI address (DT6). The dimming range ranges from 0.1%-100%. The device can be configured via the DALI Cockpit Software, e.g.: the PWM frequency (122Hz/244Hz/488Hz/976Hz). The module is also characterized by low standby losses, high efficiency, overtemperature shutdown and integrated short-circuit protection (CC).

The compact module is suitable for integration in luminaires or installation in flush-mounted installation boxes.

DALI-2 LED Power Supply 3W
Art. Nr.: 89453762-350
Art. Nr.: 89453762-500
Art. Nr.: 89453762-700

Product link: https://www.lunatone.com/en/product/dali-led-power-supply-3w/
Datasheet: https://www.lunatone.com/wp-content/uploads/2023/10/89453762_DALI2_LED-Power_Supply_3W_EN_D0121.pdf

DALI-2 LS
Art. Nr.: 68791433-__

Produkt link: https://www.lunatone.com/en/product/dali-2-ls/
Datenblatt: https://www.lunatone.com/wp-content/uploads/2023/08/68791433_DALI2_LS_EN_D0120.pdf

DALI-2 MC1L
Art. Nr.: 86458507-1L-2

Product link: https://www.lunatone.com/en/product/dali-2-mc1l/
Datasheet: https://www.lunatone.com/wp-content/uploads/2023/08/86458507-1L-2_PS_DALI-2_MC1L_PS_EN_D0119.pdf

DALI-2 MC1L PS
Art. Nr.: 86458507-1L-PS

Product link: https://www.lunatone.com/en/product/dali-2-mc1l-ps/
Datasheet: https://www.lunatone.com/wp-content/uploads/2023/08/86458507-1L-2_PS_DALI-2_MC1L_PS_EN_D0119.pdf

DALI-2 MC2L PS
Art. Nr.: 86458507-2L-PS

Product link: https://www.lunatone.com/en/product/dali-2-mc2l-ps/
Datasheet: https://www.lunatone.com/wp-content/uploads/2023/07/86458507-2L-PS_DALI-2_MC2L-PS_EN_D0118.pdf

Module to wirelessly connect spatially separated DALI lines. The wireless connection is bidirectional – control is possible from both DALI lines. Additionally, DALI queries are supported.
The wireless connection is set up using the DALI Cockpit PC Software. The device connected to the DALI Cockpit can be set to Master mode and wirelessly searches for all other modules (Slaves) within range. The Slaves can then be paired with the Master via the Cockpit Software. After paring the DALI devices in the Slave-DALI-lines can be addressed and configured wirelessly via the wireless DALI bridge that has been set up.

The range of the wireless connection is up to 300m outdoors, inside buildings, depending on construction, from 10m to 20m.

The device is suitable for flush-mounted installation boxes.
Version with integrated DALI Power Supply (Art. Nr. 89453348-PS), provides 20mA for the sub-line (up to 10 DALI ballasts).

wDALI-2 Bluetooth 5 wireless Bridge
Art. Nr.: 89453348
Version with integrated DALI Power Supply 20mA:
Art. Nr.: 89453348-PS

Product link: https://www.lunatone.com/en/product/wdali-2-bluetooth-5-wireless-bridge/
Datasheet: https://www.lunatone.com/wp-content/uploads/2023/03/89453348_wDALI2_Bridge_EN_D0117.pdf

The compact device is used to expand the DALI line.
The DALI-2 Expander is connected to the DALI line (DALI IN terminals) and behaves like a DALI ballast with a DALI address.
The devices connected to the output of the DALI-2 Expander (DALI OUT terminals) form a subordinate DALI line. The DALI operating devices in the sub-line are controlled broadcast via the address of the DALI-2 Expander. With Art. Nr. 89452937-DES, the devices in the DALI sub-line can alternatively be controlled via Switch&Dim. The DALI-2 Expander has an integrated DALI bus power supply (25mA or 200mA, depending on the device design) to supply the sub-line.
In addition to expanding the number of operating devices, the Expander can also be used to increase the cable length by 300m.
The DALI-2 Expander is available in 3 housing variants: for DIN Rail, remote ceiling installation / integration in luminaires as well as installation boxes.

DALI-2 Expander
Art. Nr. 89452937-DO
Art. Nr. 89452937-HS
Art. Nr. 89452937-DES

Product link: https://www.lunatone.com/en/product/dali-2-expander/
Datasheet: https://www.lunatone.com/wp-content/uploads/2023/03/89452937_DALI-2_Expander_EN_D0116.pdf

DALI Audio Interface
Art. Nr.: 89943721

Produkt link: https://www.lunatone.com/en/product/dali-audio-interface/
Datenblatt: https://www.lunatone.com/wp-content/uploads/2023/03/24138478_DALI-2_Audio_Interface_EN_D0115.pdf

DALI-2 USB 30mA
Art. Nr.: 24138215-30

Produkt link: https://www.lunatone.com/en/product/dali-2-usb/
Datenblatt: https://www.lunatone.com/wp-content/uploads/2023/01/24138215_DALI-2_USB30mA_EN_D0114.pdf

Module to wirelessly connect spatially separated DALI lines. The wireless connection is bidirectional – control is possible from both DALI lines. Additionally, DALI queries are supported.

The wireless connection is set up using the DALI Cockpit PC Software. The device connected to the DALI Cockpit can be set to Master Mode and wirelessly searches for all other modules (Slaves) within range. The Slaves can then be paired with the master via the Cockpit Software.

After paring the DALI devices in the Slave-DALI-lines can be addressed and configured wirelessly via the wireless DALI bridge that has been set up.

The range of the wireless connection is up to 1km outdoors, inside buildings, depending on construction, from 100m to 500m.

The device is suitable for flush-mounted installation boxes.

Version with integrated DALI Power Supply (Art. Nr. 86452785-PS), provides 20mA for the sub-line (up to 10 DALI ballasts).

wDALI-2 Extra Long Range wireless Bridge
Art. Nr.: 86452785
Version with integrated DALI Power Supply 20mA:
Art. Nr.: 86452785-PS

Produkt link: https://www.lunatone.com/en/product/wdali-2-extra-long-range-wireless-bridge/
Datenblatt: https://www.lunatone.com/wp-content/uploads/2022/11/86452785_wDALI2_ExtraLongRange_wireless_Bridge_EN_D0112.pdf

The new version DALI-2 IoT Node-RED allows easy integration into automations in Node-RED. With integrated Node-RED server.

DALI-2 IoT Gateway Node-RED
Art. Nr.: 89453886-NR

Produkt link: https://www.lunatone.com/en/product/dali-2-iot-gateway/
Datenblatt: https://www.lunatone.com/wp-content/uploads/2021/08/89453886_DALI2_IOT_EN_D0099.pdf

DALI Relays have been DALI-2 certified!
The new DALI-2 versions will replace the previous:

DALI-2 RM8 Art. Nr. 86456944
replaces DALI RM8 Art. Nr. 86458675

DALI-2 RM8 HS DIN Rail Art. Nr. 86456944-HS
replaces DALI RM8 HS Art.Nr. 86458675-HS

DALI-2 RM16  Art. Nr.: 86456203
replaces DALI RM16 Art. Nr.: 86458629

DALI-2 RM16 DE Art. Nr. 86456203-DE
replaces DALI RM16 DE Art.Nr. 86458629-DE

DALI-2 RM16 HS DIN Rail Art. Nr. 86456203-HS
replaces DALI RM16 HS Art.Nr. 86458629-HS

DALI-2 RM16 HS WE DIN Rail Art. Nr. 86456203-HS-WE
replaces DALI RM16 HS WE Art.Nr. 86458629-HS-WE

More information can be found here:

DALI-2 Relays
https://www.lunatone.com/en/product-category/operating-devices-and-actuators/dali-phase-dimmers-relays/
Datasheet:
https://www.lunatone.com/wp-content/uploads/2018/03/24034702_DALI_RM_RM8_RM16_EN_D0042.pdf

DALI-2 BT5 Room Controller KNX
Art. Nr.: 87454427-KX

Product link: https://www.lunatone.com/en/product/dali-2-bt5-room-controller-knx/
Datasheet: https://www.lunatone.com/wp-content/uploads/2022/11/87454427_DALI-2_BT5-KNX-Room-Controller_EN_D0113.pdf

With this module the exchange of a lamp or dimmer is possible without re-addressing!

DALI Proxy
Art. Nr. 89452887

Produkt link:https://www.lunatone.com/en/product/dali-proxy
Datenblatt: https://www.lunatone.com/wp-content/uploads/2022/11/89452887_DALI_Proxy_EN_D0107.pdf

Example application:

DALI-2 WLAN Cockpit Interface
Art. Nr.: 24138478
Art. Nr.: 24138478-PS

Produkt link: https://www.lunatone.com/en/product/dali-2-wlan-cockpit-interface/
Datenblatt: https://www.lunatone.com/wp-content/uploads/2022/08/24138478_DALI-2_WLAN_EN_D0109.pdf

The DALI-2 Display 7″ Emergency is a multifunctional control and operating unit for for DALI emergency light systems.

By default, the display shows the user interface for monitoring the emergency light system with the current status and results of the last performed tests.
The configuration menu can be used to schedule and automate communication, function and duration tests.
The device thus allows automatic and uncomplicated monitoring and functionality check of the emergency lighting system.
The test results are logged and can be emailed or downloaded via the display’s web interface.

DALI-2 Display 7″ Emergency
Art. Nr.: 86456840-EM-W
Art. Nr.: 86456840-P-EM-W
Art. Nr.: 86456840-EM-B
Art. Nr.: 86456840-P-EM-B

Produkt link: https://www.lunatone.com/en/product/dali-2-display-7-emergency/
Datenblatt: https://www.lunatone.com/wp-content/uploads/2022/08/86456840-EM_DALI-2_Display_7Inch_EM_EN_D0110.pdf

Example application – mixed DALI system:

The module is used in combination with a DALI-2 Display 7” Plus or DALI-2 Display 7” Emergency. It allows a DALI system expansion with up to 3 additional DALI lines.
The device has 2 Ethernet sockets for connecting the DALI-2 Display and the local network. Up to three DALI lines can be connected via terminals DA1, DA2 and DA3.
The Display Bus Extension Module requires a 24V supply (suitable power supply unit: PS 24V, 300mA, Art. Nr.: 24166012-24HS).
DIN rail housing suitable for installation in control cabinets.

DALI-2 Display Bus Extension
Art. Nr.: 86451848

Produkt link: https://www.lunatone.com/en/product/dali-2-display-bus-extension/
Datenblatt: https://www.lunatone.com/wp-content/uploads/2022/08/86451848_Display-Bus-Extension_EN_D0111.pdf

Compact DALI-2 sensor module for motion detection (PIR) & light intensity measurement.
Due to the horizontal detection angle (150 °), the sensor is particularly suitable for wall mounting, e.g. in corridors.
Multiple sensors can be used within one system.
The device is powered directly by the DALI bus. Version for indoor and outdoor use (IP65) are available.

The DALI-2 CS Corridor is available with application controller or instance mode:

DALI-2 CS Corridor with Application Controller
DALI-2 CS Corridor can be configured with the DALI Cockpit Software to send various DALI commands upon motion detection to either the entire DALI system, groups or individual addresses.
The module also contains a light sensor to deactivate motion detection when there is sufficient lighting. Activating the integrated light control unit enables DALI constant light control in a simple manner.
Art. Nr.: 88793325 und IP65: Art. Nr.: 88793325-IP65
product link: https://www.lunatone.com/en/product/dali-2-cs-corridor/

DALI-2 CS Corridor in instance mode
The module gathers measurements for a building management system (instance mode) – (DALI-2 CS Master, WAGO, Beckhoff, etc.). The measured values can either be queried or automatically trigger events. This functionality is implemented via DALI-2 instances. The DALI-2 CS Corridor Integration can be set accordingly in the DALI Cockpit Software.
Art. Nr.: 88793325-INT und IP65: Art. Nr.: 88793325-INT-IP65
product link: https://www.lunatone.com/en/product/dali-2-cs-corridor-integration/

datasheet: https://www.lunatone.com/wp-content/uploads/2022/04/88793325-and-88793325-IP65_DALI-2_CS_Corridor_EN_D0108.pdf

Interface with 4, from the DALI bus galvanically isolated, inputs for mains voltage. Each input can be individually configured with target address, button behaviour and DALI commands. The light level for each input can be conveniently adjusted on site with the 4 potentiometers on the device. The LEDs indicate the active inputs.

Besides the standard functions, dimming, switching, scene recall, etc., predefined macros such as setting the colour temperature, dynamic scenes and sequences as well as user defined command lists are supported.
In addition the DALI DT8 TC and RGB (W) control is also supported.

In the delivery state the application controller is activated.
With the DALI Cockpit PC software, the device can also be set to instance mode (no direct DALI control commands) for integration into higher-level building management systems from e.g. WAGO, Beckhoff.

For more information please check:

DALI-2 MC4L POTI
Art. Nr.: 86458507-4L-POTI
Produkt link:
https://www.lunatone.com/en/product/dali-2-mc4l-poti/
Datenblatt:
https://www.lunatone.com/wp-content/uploads/2022/02/86458507-4L-POTI_DALI-2_MC4L_POTI_EN_D0106.pdf

The KNX 4 DALI Gateway is DALI-2 and KNX certified.
The gateway enables broadcast control of 4 DALI lines, each with 4 DALI operating devices. If needed, the number of devices can be extended with a DALI Expander. The 4 DALI lines are supplied with power by the KNX 4 DALI Gateway.

The configuration of the DALI-KNX Gateway can be done with the provided product database for ETS5. The data point types that match the DALI devices can be set in the ETS5 and linked to the KNX components.
Color temperature control (DT8: CW-WW), color control (DT8: RGB, RGBW) as well as the control of other light sources (DT0, DT2, DT3, DT4, DT6) are supported. DALI scene recalls are possible with KNX communication objects for scenes.

For more information please check:

Product link:
https://www.lunatone.com/en/product/knx-4-dali/

Datasheet:
https://www.lunatone.com/wp-content/uploads/2022/01/89451312-KNX-4-DALI-Gateway_Datasheet_EN_D0105.pdf

Basics of DALI and DALI-2
Subject areas:
00:00 Intro
00:50 important DALI facts
03:06 DALI components
04:47 DALI supply
08:56 wiring
11:00 DALI commands
14:55 broadcast, addresses and groups
22:22 scenes
27:10 DALI parameters
33:47 DALI-2 control devices

Link: https://youtu.be/RWsRsXpFx7Y

• 24V DC Power Supply
• maximum output current 130mA
• compact device for installation boxes
• perfect for DALI-2 Display 4″

For more information please check:
PS 24V, 130mA Power Supply
Art. Nr.: 24166130-24

Alternative with 60mA output current:
PS 24V, 60mA Power Supply
Art. Nr.: 24166012-24

Alternative for DIN rail with 300mA output current:
PS 24V, 300mA Power Supply
Art. Nr.: 24166012-24HS

Product link:
https://www.lunatone.com/en/product-category/problem-solvers-en/accessories/

Datasheet:
https://www.lunatone.com/wp-content/uploads/2018/03/24166012-24HS_PS24V_EN_D0065.pdf

The DALI Room Controller serves as an interface between Bluetooth 5.0 and DALI.

The Lunatone smartphone application DALI-Cockpit Mobile offers a clear and simple interface with an installation assistant, various configuration options and a configurable user interface to control connected devices.

The module has an integrated bus supply (200mA) for a DALI system of up to 64 DALI devices. The independent control gear is suitable for remote ceiling installation or integration in luminaires.

DALI-2 BT5 Room Controller
Art. Nr.: 87454427

Product link: https://www.lunatone.com/en/product/dali-2-bt5-room-controller/
Datasheet: https://www.lunatone.com/wp-content/uploads/2020/11/87454427_DALI-2_BT5-Room-Controller_EN_D0094.pdf
Smartphone App: https://www.lunatone.com/wp-content/uploads/2020/11/87454427_DALI-2_BT5-Room-Controller_APP_GER_M0020-1.pdf

Application example:

This compact module converts 4-20mA signals to DALI dim levels. The 4-20mA current value is sent Broadcast as a dimming value on the DALI bus.
The module has an integrated bus power supply for a small DALI system with up to 10 standard DALI ballasts (30mA).
The configuration of the dimming characteristics is possible with the help of jumpers. An additional configuration with the DALI Cockpit Software is not possible.

Versions for 24V supply or mains supply are available.
The module Art. Nr.: 86468334-24-HS requires a 12- 24V power supply (e.g. 24V/300mA Art.Nr. 24166012-24HS)
The module Art. Nr.: 86468334-230-HS can be supplied with 230V mains voltage.

For more information please check:

4-20mA to DALI Converter, 24V
Art. Nr.: 86468334-24-HS
Product link:
https://www.lunatone.com/produkt/4-20ma-to-dali-converter-24v/
Datasheet:
https://www.lunatone.com/wp-content/uploads/2021/11/86468334-24-HS_4-20mA_to_DALI_PS30mA_Converter_24V_EN_D0102.pdf

4-20mA to DALI Converter, 230V
Art. Nr.: 86468334-230-HS
Product link:
https://www.lunatone.com/en/product/4-20ma-to-dali-converter-230v/
Datasheet:
https://www.lunatone.com/wp-content/uploads/2021/11/86468334-24-HS_4-20mA_to_DALI_PS30mA_Converter_24V_EN_D0102.pdf

DALI Sequencer is a control unit to recall automatically timed instruction sequences. A sequence can combine various command-sequences and scene- recalls. 4 different sequences can be defined. The active sequence is started and stopped using DALI commands. Sequences can be executed once or looped. Housings for DIN Rail mounting and back box installation are available.

The back box version provides 4 potential free inputs to start the sequences. The DIN Rail type provides 4 switching inputs for mains voltage to start the sequences, and 4 LEDs to indicate active sequences.

Easy configuration via DALI-Cockpit PC Software.

For more information please check:

Product link:
https://www.lunatone.com/en/product/dali-2-sequencer/

Datasheet:
https://www.lunatone.com/wp-content/uploads/2021/11/89453371_DALI-2_Sequencer_EN_D0101.pdf

RGBW User Interface
Control of RGBW color + white channel is now possible with the layout G09A.
A large RGBW area and a brightness slider are available,
as well as 4 buttons for scenes and an ON / OFF toggle.
Art. Nr.: 24035410-G09A
Art. Nr.: 24035410-PS-G09A

DALI Bus Power Supply of 70mA
All DALI-2 Touchpanels are now also available with an integrated DALI bus power supply of 70mA.
DALI-2 Touchpanel PS
Art. Nr.: 24035410-PS-G__
with user interface of your choice G000 or G01A to G09A

For more information please check:

Product link:
https://www.lunatone.com/produkt/dali-2-touchpanel/

Datasheet:
https://www.lunatone.com/wp-content/uploads/2020/11/24035410_DALI-2_Touchpanel_EN_D0092-1.pdf

Rotary and push button with capacitive sensor buttons for quick and precise control of brightness, colour, or colour temperature. Functionality and effective range for the rotary pushbutton can be set with the 3 or 5 capacitive buttons. The capacitive button will light up after being pressed to indicate the selected mode, the rotary knob will then control for example colour or brightness. Furthermore, it is possible to send individual DALI commands via the capacitive buttons to e.g., recall a scene. Several standard user interfaces are available and customer-specific designs can be implemented upon request.

The DALI-2 ROT Touch supports, in addition to the configuration via the DALI Cockpit PC Software, the adjustment of selected settings via smartphone (NFC capable) and the Lunatone NFC app.

The device can be mounted on commercially available flush- type installation boxes. It is directly supplied by the DALI line. A version with DALI bus power supply (-PS) is also available.
The -INT module only supports the instance mode (sending event messages instead of direct control commands) for integration in higher-level building management systems with DALI connection, such as those from WAGO or Beckhoff.

DALI-2 ROT Touch
Datenblatt: https://www.lunatone.com/wp-content/uploads/2021/08/86459338-3T_86459338-5T_DALI2_ROT_TOUCH_EN_D0100.pdf

L1: groups and scenes
Produkt link: https://www.lunatone.com/en/produkt/dali-2-rot-touch/

L2: groups, scenes and blinds
Produkt link: https://www.lunatone.com/en/produkt/dali-2-rot-touch-l2/

L3: Tunable White and scenes
Produkt link: https://www.lunatone.com/en/produkt/dali-2-rot-touch-l3/

L4: RGB and scenes
Produkt link: https://www.lunatone.com/en/produkt/dali-2-rot-touch-l4/

Application example for DALI-2 ROT Touch Tunable White:

DALI-2 IoT Gateway is an interface to connect the DALI system with smart devices over the Internet of Things (IoT). With the DALI IoT Gateway, a simple realization of an intelligent system is possible, in which devices can be controlled and monitored with smartphones, PCs, etc. It is also possible to link several DALI lines. An API documentation is available, to enable energy monitoring, remote support, and many other applications. (RESTFul API endpoints and WebSocket with JSON syntax, encrypted (optionally unencrypted) for custom integrations). The device allows integration in any IoT application using the available Software Development Kit (SDK).

DALI-2 IoT Gateway
Art. Nr. 89453886

Produkt link: https://www.lunatone.com/en/product/dali-2-iot-gateway/
Datenblatt: https://www.lunatone.com/wp-content/uploads/2021/08/89453886_DALI2_IOT_EN_D0099.pdf

Typische Anwendung:

Compact sensor modules for DALI and DALI-2 light control systems, with integrated motion detection (PIR) and light intensity measurement. Depending on the version with temperature, humidity, air pressure and air quality sensors. The modules can either be used to directly control the DALI system (application controller) or simply to gather measurements for a building management system (instance mode).

The DALI-2 multifunctional Sensors can be configured with the DALI Cockpit PC Software. For example, the light sensor can be set to automatically adjust room lighting (constant light control). 4 operating modes are supported: presence triggered constant light control; presence triggered lighting; constant light control; light control via threshold switches. In addition, alternative behaviour and parameters can be set, for example to change between different destination addresses or light values.
The measured values can be read out via the DALI line.

Multiple sensors within one group will synchronise automatically. The device is powered directly by the DALI bus.

Various housings are available: for direct mounting on cavity walls or installation boxes (standard), for suspended ceilings (with spring), for surface mounting (with backbox) as well as versions for installation in luminaires. Available housing colours are pure white RAL 9010, traffic white RAL 9016 (-W16) or black (-B).

DALI-2 CS sensor for motion & light, Application Controller and Instance Mode: https://www.lunatone.com/en/produkt/dali-2-cs/

DALI-2 CS Integration sensor for motion & light, Instance Mode: https://www.lunatone.com/en/produkt/dali-2-cs-integration/

DALI-2 CS Integration THP sensor for motion & light + temperature, relative humidity & air pressure, Instance Mode: https://www.lunatone.com/en/produkt/dali-2-cs-integration-thp/

DALI-2 CS Integration THP-AQ sensor for motion & light + temperature, relative humidity, air pressure & air quality, Instance Mode: https://www.lunatone.com/en/produkt/dali-2-cs-integration-thp-aq/

for installation in luminaires:

DALI-2 CS Integration THP LE sensor for motion & light + temperature, relative humidity & air pressure, for installation in luminaires, Instance Mode: https://www.lunatone.com/en/produkt/dali-2-cs-integration-thp-le/

DALI-2 CS Integration THP-AQ LE sensor for motion & light + temperature, relative humidity, air pressure & air quality, for installation in luminaires, Instance Mode: https://www.lunatone.com/en/produkt/dali-2-cs-integration-thp-aq-le/

The latest innovations and additions to the Lunatone product portfolio are summarised here:

Link to: 2021 catalog _ Lunatone DALI Highlights 2021

From small systems to extensive large installations, Lunatone offers a suitable control solution.

The push button couplers have been updated, DALI-2 certified and with the added NFC access they are now more practical than ever.

The touchpanel has undergone a design upgrade both in software and hardware in order to achieve an edge-to-edge glass front and an extra slim profile.

Also the Display received an update with several customisable control pages, buttons and sensor monitors and a flexible, user friendly interface. The new hardware is available in two sizes, 4″ and 7″.

For next level control we suggest to have a look at the DALI Room Controller. It is the perfect solution for all small installations. The device provides both the bus power supply as well as a Bluetooth 5.0 connection to the smartphone app DALI Cockpit Mobile. The App allows quick and easy addressing and commissioning of all connected DALI devices. Additionally the app offers a convenient user interface for device control.

DALI PS2 80mA serves as power supply for a medium-sized DALI installation with up to 40 standard DALI ballasts. Voltage and current limitation according to standard as well as timing ensure a reliable bus communication. With the output current of up to 80mA a medium-sized DALI installation can be supplied. Up to 40 addressable DALI devices and control modules (DALI Sensors, MC, Touch panel…) can be connected, up to an overall load of 80mA. The device is suitable for installation in flush-mounted installation boxes.

DALI PS2 80mA
Art. Nr.: 24033444-80

Produkt link: https://www.lunatone.com/en/product/dali-ps2-30-ma/
Datenblatt: https://www.lunatone.com/wp-content/uploads/2018/04/24033444-30_DALI_PS2_30mA_EN_D0078.pdf

Control devices tailor-made for your DALI installation

With the new product configurator, the user interface of the DALI-2 Touchpanel and all DALI Switch Cross variants can now be easily customised. A large selection of symbols and templates are available, but you can also load your own data. This way you will receive a tailor-made product perfect for your installation and your ambient.

The configurator guides you step by step from frame color and design to device settings. The 3D viewer visualises all of your settings. After everything has been configured to your liking, you can send a non-binding inquiry directly to Lunatone via the configurator.

We wish you a lot of fun creating your individual lighting control!

Configurator for DALI-2 Touchpanel user interface: https://configurator.lunatone.com/touchpanel?lang=en

Configurator for DALI Switch Cross user interface: https://configurator.lunatone.com/switchcross?lang=en

Compact DALI-2 control module for connection of up to 4 EnOcean pushbuttons to the DALI system. Each of the 4 EnOcean inputs can be individually configured with effective range, switching functions and DALI commands. Besides the standard functions, dimming, switching, scene recall, etc., predefined macros such as setting the colour temperature, dynamic scenes and sequences as well as user defined command lists are supported. The device is designed to fit a flush-type installation box.

With variant 86463327-app, the application controller is activated. In addition to the standard DALI commands, the DALI DT8 TC and RGB (W) control is also supported. The device can also be set to instance mode with the DALI Cockpit PC Software.

The variant 86463327-int is set to instance mode (no direct DALI control commands) for integration into higher-level building management systems from e.g. WAGO, Beckhoff. The application controller can be activated with the DALI Cockpit PC Software.

With the 86463327-NFC version, selected settings are adjustable using a NFC ready smartphone and the Lunatone NFC App (in addition to configuration via the DALI Cockpit PC Software).

For more information please check:

Product link:
https://www.lunatone.com/en/product/enocean-dali-2-mc/

Datasheet:
https://www.lunatone.com/wp-content/uploads/2022/01/86463327-DALI-2_MC-EnOcean_EN_D0104.pdf

We would like to congratulate the Sielight team from Greece to receive the DALI Lighting Award “HIGHLY COMMENDED TECHNICAL SOLUTION”.

The Lunatone controllers have been used to their best potential. This application is a wonderful example of the excellent use of DALI CDC and many other Lunatone devices.

More information abut the installation: https://www.dali-alliance.org/awards/sielight-trap.html

Sielight: www.sielight.gr

The capacitive 7” colour display with 24-bit colour depth allows both the configuration, as well as the control and operation of a DALI system. Numerous widgets enable customisation. Supported functions are dimming and switching of groups, recall of scenes, RGB colour management and colour temperature control, etc. DALI, USBmini and WLAN are available as interfaces. The measurement of temperature, humidity, air pressure, air quality etc. is also possible via integrated sensors.

DALI-2 Display 7″
Art. Nr.: 86456840-W
Art. Nr.: 86456840-P-W

Product link: https://www.lunatone.com/en/product/dali-2-display-7/
Datasheet: https://www.lunatone.com/wp-content/uploads/2020/11/86456840_DALI-2_Display_7Inch_EN_D0095.pdf

Typische Anwendung:

The capacitive 4” colour display with 24-bit colour depth allows both the configuration, as well as the control and operation of a DALI system. Numerous widgets enable customisation. Supported functions are dimming and switching of groups, recall of scenes, RGB colour management and colour temperature control, etc. DALI, USBmini and WLAN are available as interfaces. The measurement of temperature, humidity, air pressure, air quality etc. is also possible via integrated sensors.

DALI-2 Display 4″
Art. Nr.: 86456841-W
Art. Nr.: 86456841-P-W

Product link: https://www.lunatone.com/en/product/dali-2-display-4/
Datasheet: https://www.lunatone.com/wp-content/uploads/2020/11/86456841_DALI-2_Display_4Inch_EN_D0093.pdf

Application example:

The DALI-2 Touchpanel is a multifunctional control unit with up to 16 freely configurable buttons. The number of keys and the assigned DALI commands can be set in the DALI Cockpit Software. The device can be adapted to a wide variety of applications. A large number of layouts are available and custom layouts can be realised upon request.

Besides the standard functions, dimming, switching, scene recall, etc., predefined macros such as setting the colour temperature, dynamic scenes and sequences, as well as user defined command lists are supported.

DALI-2 Touchpanel
Art. Nr.: 24035410

Product link: https://www.lunatone.com/en/product/dali-2-touchpanel/
Datasheet: https://www.lunatone.com/wp-content/uploads/2020/11/24035410_DALI-2_Touchpanel_EN_D0092-1.pdf

Application example:

Compact sensor module with integrated motion detection (PIR), light intensity measurement and light control unit.
In addition to the standard detection in the outer area, DALI CS Mini has a more sensitive inner detection area for the detection of minor movements.

DALI CS Mini can be configured with the DALI Cockpit Software to send various DALI commands upon motion detection to either the entire DALI system, groups or individual addresses.
The module also contains a light sensor to deactivate motion detection when there is sufficient lighting. Activating the integrated light control unit enables DALI constant light control in a simple manner.
Short-term external brightness fluctuations (e.g. car headlights) can be dealt with using the adjustable time hysteresis.
Several sensors can be used in a group; the sensors are synchronised automatically.
The device is powered directly by the DALI bus.

It is available in two different versions: for indoor and outdoor use (IP65).

DALI CS Mini
Art. Nr.: 86457244

DALI CS Mini IP65
Art.Nr.: 86457244-IP65

Produkt link: https://www.lunatone.com/en/product/dali-cs-mini/
Datenblatt: https://www.lunatone.com/wp-content/uploads/2020/10/86457244-und-86457244-IP65_DALI_CS_Mini_EN_D0091.pdf

Compact sensor module with integrated motion detection (PIR), light intensity measurement and light control unit.
Due to the horizontal detection angle (150 °), the sensor is particularly suitable for wall mounting, e.g. in corridors.

DALI CS can be configured with the DALI Cockpit Software to send various DALI commands upon motion detection to either the entire DALI system, groups or individual addresses.
The module also contains a light sensor to deactivate motion detection when there is sufficient lighting. Activating the integrated light control unit enables Dali constant light control in a simple manner.
Short-term external brightness fluctuations (e.g. car headlights) can be dealt with using the adjustable time hysteresis.
Several sensors can be used in a group; the sensors are synchronised automatically.
The device is powered directly by the DALI bus.

It is available in two different versions: for indoor and outdoor use (IP65).

DALI CS Corridor
Art. Nr.: 86459432

DALI CS Corridor IP65
Art. Nr.: 86459432-IP65

Product link: https://www.lunatone.com/en/product/dali-cs-corridor/
Datasheet: https://www.lunatone.com/wp-content/uploads/2020/10/86459432_86459432-IP65_DALI_CS_Corridor_EN_D0020.pdf

The KNX DALI-2 Gateway is DALI-2 and KNX certified. It is DALI multimaster capable and can transmit commands bidirectional from KNX to DALI and vice versa. The DALI system and the individual DALI devices can be configured with the DALI Cockpit PC Software. Via the gateway’s product database in the KNX ETS Software the DALI devices can be matched with the respective data points and linked to the KNX components. All DALI device types (DT6, DT8-CW-WW, RGB, RGBW, RGBWAF, X-Y) are supported.

KNX DALI-2 Gateway
Art. Nr. 89453899

Produkt link: https://www.lunatone.com/en/product/knx-dali-2-gateway/
Datenblatt: https://www.lunatone.com/wp-content/uploads/2020/09/89453899-KNX-DALI-Gateway_Datasheet_EN_D0090-1.pdf

Application example:

Module for the wireless connection of spatially separated DALI loads to a DALI system with BT5 Long Range. The transmitter sends DALI commands from the DALI system to one or more receivers. The receiver is available with or without an integrated DALI bus supply. The devices in the sub-circuit can be controlled via broadcast or an assigned group. Easy configuration with DALI Cockpit Software.
Support of DALI-2 control commands.

wDALI-2 BT5 Long Range Transmitter
Art. Nr.: 89453321-GRTM

wDALI-2 BT5 Long Range Receiver
Art. Nr.: 89453321-GRR

wDALI-2 BT5 Long Range Receiver PS20
Art. Nr.: 89453321-GRRPS

Product link: https://www.lunatone.com/en/product/wdali-2-bt5-long-range-transmitter-receiver/
Datasheet: https://www.lunatone.com/wp-content/uploads/2020/08/wDALI2_BT5_Long_Range_Transceiver_EN_D0083_21Aug2020.pdf

Application example:

The DALI Flash USB enables the communication between the DALI Cockpit PC Software and devices on the DALI bus. A flash memory is available to store the bus configuration and all device settings. Thus they are permanently available, regardless of the PC used for initial configuration. The DALI Flash USB is suitable for DIN rail mounting.

DALI Flash USB
Art. Nr. 89454248

Product link: https://www.lunatone.com/en/product/dali-usb/
Datasheet: https://www.lunatone.com/wp-content/uploads/2018/03/24138923_DALI_USB_EN_D0052-1.pdf

Application example:

Pushbutton coupler with 4 inputs to connect standard potential-free switches or pushbuttons. New functions, DALI-2 and NFC configuration!

Each input can be individually configured with target address, button behaviour and DALI commands. Besides the standard functions, dimming, switching, scene recall, etc., predefined macros such as setting the colour temperature, dynamic scenes and sequences as well as user defined command lists are supported. The device is designed to fit behind a switch in a flush-type installation box. In addition to the configuration with the DALI Cockpit PC Software, selected settings are adjustable using a NFC ready smartphone and the Lunatone NFC App.

DALI-2 MC
Art. Nr. 86459532-2-app
factory default setting: App-Controller activated

Art. Nr. 86459532-2-int
factory default setting: Instances activated

DALI-2 MC NFC
Art. Nr. 86459532-NFC
factory default setting: App-Controller activated

Produkt link: https://www.lunatone.com/en/product/dali-2-mc/
Datenblatt: https://www.lunatone.com/wp-content/uploads/2020/08/86459532-DALI-2_MC_EN_D0084-2.pdf

Application example:

Compact control module for automatic power reduction / brightness reduction for night-time.

DALI LR PS20
Art. Nr.: 89453880
product link: https://www.lunatone.com/en/product/dali-lr-ps20/
datasheet: https://www.lunatone.com/wp-content/uploads/2020/08/DALI_LR_20mA_EN_D0085.pdf

With only one DT6 DALI address, the Dim2Warm module allows the simultaneous control of brightness while changing the colour temperature. The lower the dimming value, the warmer the light.

Any 2 DALI devices can be connected to the output.
The output mode can be set via the DALI Cockpit Software:
1. separate output of warm and cold white
2. joint output of warm and cold white at two outputs
The dimming curve can also be set individually for each output.

This interface is also interesting for special applications, e.g. control of direct and indirect lighting with a single DALI address.

DALI Dim2warm
Art. Nr.: 89453864
Product link: https://www.lunatone.com/en/product/dali-dim2warm/
Datasheet: https://www.lunatone.com/wp-content/uploads/2020/06/89453864_DALI_Dim2warm-_EN_D0082-1.pdf

Application example:

The DALI Expander is now available in a narrower housing!

The compact design enables installation in small luminaires, profiles and rails.

DALI Expander S
Art. Nr. 89453847-S
Produktlink: https://www.lunatone.com/en/product/dali-expander/
Datenblatt: https://www.lunatone.com/wp-content/uploads/2018/03/DALI_Expander_EN_D0027.pdf

Lunatone offers DALI products for almost all applications. With this product folder we want to facilitate the search for the right product.

Link to: 2019 Product Catalog _ Lunatone DALI Light Management Systems

Modules to control and send command are listed in section A “Input Devices, Control Units & Sensors”, which includes pushbutton couplers, rotary dimmers, touch panels, sensor modules, etc.

In part B you will find Phase dimmers & Actuators.

Modules that receive DALI signals to operate e.g. luminaries are located in part C “Operating Devices 230VAC / 48V / 24V”.

All DALI modules require a DALI bus supply, these are in section D together with devices for expanding the system.

The last part contains programming tools and interface modules to other control systems.

DALI ROT is the world’s first multi-master control unit to successfully complete the DALI 2 certification!

DALI ROT replaces potentiometer based rotary dimmers, which were limited to on/off and controlling brightness. Functions such as on/off, controlling brightness levels as well as colour temperature and colour are supported by this innovative device.

DALI ROT product page

Now also DALI-2 certified: DALI SCI RS232

all DALI-2 certified devices

Several Lunatone DALI Devices are now ENEC and UL certified.

ENEC and UL certificates can be found in our Downloads A-Z

Lighting Event from 24th to 26th of September

Lunatone introduces the latest products, applications and technical innovations.
Among other new DALI controls and DALI products for the integration of KNX and IoT.

July 2019 – Lunatone controller applications

Content:

• Lunatone product portfolio
• DALI basics
• Concept Lunatone Controls / Examples
• DALI Cockpit Software Tool
• Hands on Training 1: Applications Broadcast
• Hands on Training 2: Applications Addressed
• Error diagnosis and tests

Date and Location:
09:00 – 16:30, Lunatone headquarters in 1210 Vienna
Tuesday, 23rd of July 2019 – course language: German
Wednesday, 24th of July 2019 – course language: English

Requirements & Costs:
For registration, please send an e-mail including your complete address and desired date to: dali-kurse@lunatone.com
The number of participants is min. 5 and max. 12 people. The order of registration follows the date of receipt. Registrations are binding.

Euro 490, – (excluding VAT)
including meal and 1 piece of DALI USB 30mA worth Euro 186, -.
Please bring a laptop with installed DALI Cockpit software.

DALI Daylight Interface with iOS and Android application is a convenient configuration tool for DALI devices.


Once the basic settings have been defined in DALI Cockpit, the device parameters such as daylight curve, timer, schedules, brightness, color temperature, etc. can be set with a mobile device.

DALI Daylight Interface product page

Lunatone introduces the next innovation in the field of DALI: DALI ROT, a rotary switch.

DALI ROT replaces potentiometer based rotary dimmers, which were limited to on/off and controlling brightness.

As of now functions such as on/off, controlling brightness levels as well as colour temperature and colour are supported by this innovative device.

Lunatone is on the road to DALI-2 certification.

Our development team has started work on this subject. As first products we have already certified 2 DALI bus power supplies and further products will follow soon.

new operating types:

• Balance&Dim: two DALI addresses, address1 to control brightness, address2 to control colour temperature.
• Dim2Warm: one address to dim and simultaneously change colour temperature (the lower the dim value the warmer the colour temperature)
• Colour&Dim: two DALI addresses, address1 to control brightness, address2 to control colour.
• SwitchDim2: two switch inputs, enables for example tunable white and colour control without DALI (switch1 for brightness, switch2 for colour)

new functions:

• dimm range 0.1%-100%
• adjustable PWM frequency from 244Hz up to 1kHz, for all CV devices
• optional broadcast-control
• adjustable Tc-increment(forCW-WW)

Content:

• Lunatone product portfolio
• DALI basics
• Concept Lunatone Controls / Examples
• DALI Cockpit Software Tool
• Hands on Training 1: Applications Broadcast
• Hands on Training 2: Applications Addressed
• Error diagnosis and tests

Date and Location:
09:00 – 16:30, Lunatone headquarters in 1210 Vienna
Tuesday, 24.07.2018 – course language: German
Wednesday 25.07.2018 – course language: German
Thursday 26.07.2018 – course language: English

Requirements & Costs:
For registration, please send an e-mail including your complete address and desired date to: dali-kurse@lunatone.com
The number of participants is limited to max. 12 people. The order of registration follows the date of receipt. Registrations are binding.

Euro 490, – (excluding VAT)
including meal and 1 piece of DALI USB 30mA worth Euro 186, -.
Please bring a laptop with installed DALI Cockpit software.

Innovative thinking requires space. The same applies to result oriented and highly productive working.

To make sure that the ‘Lunatone spirit’ will be preserved for the future to come, we have moved to a new company building. The Lunatone head quarter has been designed and furnished with the most modern and innovative principles in mind. Special attention was paid to offer our employees up-to date workspaces and an adequate infrastructure. Surrounded by technology institutes and market leaders, the new location has been strategically selected. Well connected to public transport and parking area, as well as sufficient space for building extensions round off the advantages of the new location.

In the course of this project the machine park has been expanded. Modern, CNC managed, machining centres as well as a water jet cutter have further increased our flexibility.

At the new location we could combine development, construction, test laboratory, service, acquisition, sales and administration under one roof.

Thereby Lunatone will continue to be your innovative partner for Light Management Systems and Industrial Electronics.
